Your new microchip reader. The Trovan Wand.
Suitable for Companion Animal ISO microchips and Livestock HDX ear-tags, with high performance, ease of use and versatility.
This rugged tool with an ergonomic design makes your tasks easy. It has Bluetooth technology that allows you to connect your reader with scales and other devices to share information simultaneously.
- Alphanumeric keyboard
- An easy to read OLED screen when working outside
- Quick reading, with sound , vibration and LED lights
- Customisable attribute list to characterise all your readings.
- Download your readings by USB to your PC (Windows/Mac) very easily
It's time to go PRO.
Greater control and peak performance with the Pro.
- Upgraded Alphanumeric Keyboard
- Registers Up To 35 Characteristics Per ID Read (8x more than the standard Trovan Wand Reader)
Overview
Greater Comfort: It weighs only 680 grams with an ergonomic design
It Has What It Takes: Personalise attributes for each animal to record the information that is important to you
More Than A Tool: Registers up to 4 characteristics for each ID read (Up to 35 characteristics)
ISO Compliant: The readers have the RFID technology to read all the ISO protocols; HDX and FDX-B tags, certified in compliance with ISO11784 and ISO11785 standards
A Long & High Performance: High capacity battery that lasts a whole workday
Get Connected: It has Bluetooth technology to connect with scales and other devices, and also USB for PC
Storage: It has a great storage capacity that can backup up to 1.1 million readings
Reading Capability: Reads anywhere along the pole extension with fast readings and continuous reading mode to maximise your time
Weather Resistant: Designed to withstand a variety of weather conditions
Easy Management: Free software is provided that allows you to edit, save and manage all your readings
Technical Specs
| Dimensions | 660mm x 68mm x 50mm |
| Weight | 680g |
| RFID Tag technology | 134,2 kHz (+/- 100 ppm) |
| Compliant With ISO | ISO11784 and ISO11785 standards |
| Reading Distance | ISO FDX-B (120mm), ISO HDX (Up to 300mm) |
| Reading Speed | Up to 80 readings/minute |
| Data Storage Capacity | Flash Memory (16mb), SD Card (Up to 32gb) Backup up to 1.1 million readings |
| Connectivity | USB, Bluetooth |
| PC Requirements | USB port. Windows XP or later, or MAC |
| Screen | OLED Screen 128x64 pixels |
| Controls | Alphanumeric |
| Battery | Rechargeable lithium ion 7.4 VDC 2200 mAh. |
| Battery Autonomy |
14 hours of continuous work (in continuous reading mode) |
| Operating Temperature | -10°C a +55°C |
| Storage Temperature | -25°C a +70°C |
| Operating Humidity | 0% a 80% |
| Housing Material | ABS and fibreglass |
